24v 1.5a smps led switching power supply

  • SMT-024-036SA
  • 1
  • Xiamen
  • China
  • about 7 working days
  • CONTACT US NOW
  • Product Detail

24v 1.5a smps led switching power supply


24v 1.5a smps led switching power supply is  CE(EMC,LVD standard)  ROHS approval, 2 years warranty, low operation temperature.


Specification of 24v led switching power supply

Model

SMT-005-036SA

SMT-012-036SA

SMT-024-036SA

SMT-036-036SA







output

DC voltage

5V

12V

24V

36V

Voltage tolerance

±1%

±1%

±1%

±1%

Rated current

5A

3A

1.5A

1A

Rated power

25W

36W

36W

36W

Ripple&noise

150mvp-p

150mvp-p

150mvp-p

150mvp-p

DCvoltage ADJ.range

±10%

±10%

±10%

±10%





input

Voltage range

100~240Vdc

frequency

47~63HZ

efficiency

82%

82%

82%

82%

Inrush current

Cold start current 18A/115VAC,36A/230VAC

Leakage current

< 1mA/240VAC



protection

overload

Rated output power115%~150% start over load protection

protection type:cutoff output,recovery after restart power

Over voltage

15.6~17.8V

18.6~20.8V

30.6~33.2V

33.2~35.6V

protection type:hiccup mode,auto-recovery after fault condition is removed

-----

-----

-----

environment

Working temp,humidity

-10°C~+60°C,20%~90%RH

Storagetemp,humidity

-20°C~+85°C,10%~95%RH non-condensing

Withstand vibration

10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes

safety

Withstand voltage

I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Isolated resistance

I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC

  • Case material:metal case
  • CE(EMC,LVD standard) UL/CUL ROHS approval
  • 2 years warranty


Feature of led switching power supply

  • Competitived price and high reliability
  • AC input power suitable for the world
  • High efficiency and low operation temperature
  • Soft-start current can reduce the AC input impact effect
  • With short-circuit and overload protection
  • Compact size, light weight
  • 100% full-load burn-in test
  • Installed with EMI filter, minimum wave


Shipping and packing of 24v 1.5a smps

ul listed dc24v power supply enclose for cameras cctvul listed dc24v power supply enclose for cameras cctv


Why choose Quanzhou Smarts Electronic & Technology Co.,Ltd ???


1).  Our major markets are in EU & North America,it takes about 85% markets share,that to say we do high quanlity power suppliers only.

2).  Most of our products are approved with UL/CE/Rohs approval, our ULfile#E365202.

3).  We give 2 years warranty

4).  We accept trial orders begining..


5). We  have an area of 2000 square meters factory,  about 300-500 production staff. ..


FAQ:

Q1.            What's type power supply do you have?

Answer:     We specialized in constant voltage & current LED drivers,

                  0- 10v/triac/DALI dimmable led drivers, enclosure power suppliers, power adapters



Q2.             What's shipping mode can we choose?

Answer:      1.FedEx/DHL/UPS/TNT/Express for samples;

                   2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

                   3. Customers specifying freight forwarders or negotiable shipping method



Q3.             What's the MOQ?

Answer:      Our MOQ is 500pcs, but we accept your trail order/small order, no problem.



Q4.             What can you do if the product is broken?

Answer:      We promise to replace new ones to you if there is any defective happen

                   during the warranty period, but we need pictures or video to prove the defective

                   comes from our quality problem



Q5.             How about the protection of product?

Answer:      Most of our products have protection of short-circuit. overload,
                   over voltage, over current and reserve polarity. About the specific product,

                   please consult our salesstuff.



Q6.              How about the transportation?

Answer:       For small order,express will be best.And for bulk order,sea ship way is best but take much time.

                    For urgent orders,we suggest via air to airport plus our ship partner send to your door.

                    We will cooperate with your choice.



Q7.              What's the Payment do you have?

Answer:       To assure you the maximum comfort and satisfaction, Currently, you can pay via T/T, L/C,

                    WESTERN UNION, PAYPAL. More payment options will be added in the near future.
