Non-dimmable LED Driver

5v 20amp smps transformer enclosure

smps enclosure; smps 20amp; 5v smps transformer
  • item no.:

    SMT-005-100SA
  • lead time:

    15 working days for 500pcs
  • product orgin:

    China
  • brand:

    SMARTS
  • shipping port:

    xiamen
  • payment:

    T/T, Paypal, Western Union
inquiry now
product details

5v 20amp smps transformer enclosure

Product Description

Product parameters:

Model

SMT-005-100SA

SMT-012-100SA

SMT-015-100SA

SMT-024-100SA

SMT-036-100SA

SMT-048-100SA







output

DC voltage

5V

12.5V

15V

24V

36V

48V

Voltage tolerance

±2%

±1%

±1%

±1%

±1%

±1%

Rated current

20A

8.33A

6.6A

4.17A

2.78A

2.08A

Current range

0~20A

0~8.33A

0~6.66A

0~4.17A

0~2.78A

0~2.08A

Rated power

100W

100W

100W

100W

100W

100W

Ripple&noise

100mvp-p

150mvp-p

150mvp-p

150mvp-p

150mvp-p

150mvp-p

DCvoltage ADJ.range

± 10%

±10%

±10%

±10%

±10%

±10%





input

Voltage range

100~240Vdc

frequency

47~63HZ

AC current

3.2A/115VAC,1.6A/230VAC

efficiency

83%

82%

82%

83%

82%

83%

Inrush current

Cold start current 18A/115VAC,36A/230VAC

Leakage current

< 1mA/240VAC



protection

overload

Rated output power115%~150% start over load protection

protection type:cutoff output,recovery after restart power

Over voltage

6.8~8.2V

15.6~17.8V

18.6~20.8V

30.6~33.2V

33.2~35.6V

54.8~56.6V

protection type:hiccup mode,auto-recovery after fault condition is removed

environment

Working temp,humidity

-10°C~+60°C,20%~90%RH

Storagetemp,humidity

-20°C~+85°C,10%~95%RH non-condensing

Withstand vibration

10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes

safety

Withstand voltage

I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Isolated resistance

I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC

Fitstandard


EMC standard

Comply with EN55022,CLASSA

others

Dimension

160*88*34mm (L*W*H)

Weight/packing

0.65kg/20pcs/13.5kg/0.0318 m³

note

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation



  • CE,ROHS approval
  • 2 years warranty (We promise to replace new ones to you if there is any defective happen during the warranty period)

Features:

  • Constant voltage design with high accuracy.
  • International wide input voltage.
  • output voltage 5v/12v/24v/36v/48v selectable.
  • Wattage: 15w-600w.
  • High efficiency, save energy, protected environment.
  • High stability and low ripple, increase light efficiency and decrease light attenuation.
  • Meet to safety standard and EMC.
  •  Assure LED stability long lift and light efficiency by constant voltage.
  • 9. Overcurrent, overvoltage, overheat, short curcuit protection:Auto-recovery
  • 10. Start,raise,stable time:  500ms,30ms,40ms/230VAC,500ms,30ms,16ms/115VAC
  • 11. Cooling by free air convection.
  • 12. 100% full load burn-in test.
  • 13. Brand electrotronic components.
  • 14. ROHS material.
  • 15. Well match with LED guardrail lamp, Flood light, light word, street lamp etc, For LEDs series-parallel.

Application:

  • indoor LED illuminating lights, LED Neon
  • LED urban Decoration,LED Lighting Advertising
  • LED Display, Safety Protection Apparatus
  • Telecommunications, Networks
  • Vehicle Lights, Controller Panels

5v 20amp smps transformer enclosure

Packaging & Shipping
Packing
N.W./pcs G.W/ctn Qty/ctn Carton Size( )
5v 20amp smps transformer enclosure
650g/pcs 13.5kg/ctn 20pcs 0.0318 m³




Company Information
Quanzhou Smarts Electronic & Technology Co.,Ltd (SMARTS INDUSTRIAL (HOLDING) CO LTD) was founded in 1998. The company is located in a developed economy, abundant resources, beautiful scenery of Quanzhou city Licheng district town pontoon, the company has an area of 2000 square meters, production workshop, warehouse, office, living facilities complete with. With the development of society, human increasing awareness of "green energy, environmental protection, save energy" becomes...View this Supplier's Website

Our team

5v 20amp smps transformer enclosure

Factory & Equipments view

5v 20amp smps transformer enclosure

 CE ROHS Certification


Our Services
  • We are CE ETL audited LED drivers/power supplies enterprise in China
  • Alibaba assessed 6 years Gold Supplier and more than 10 years LED industrial  experience. It will guarantee your order 100% safe
  • Price is negotiable if you have large quantity demand
  • 100% QC inspection Before Shipping
  • Best Quality & Best Service with Competitive price
  • Shipping will be the most economical for you and freight cost is informed in advance
  • consideration.decision for the shipping terms will be made according to your requirements
  • We have our engineer team, if you have any question about your LED applications, let  us know freely, we will give you the best solution
  • Our trade manager is online 12 hours. and we will reply your inquiry within 8 hours
  • OEM design & OEM packing welcome
  • Samples will be ready within 7 working days
FAQ

Q1. What's type power supply do you have?

A1: We specialized in constant voltage & current LED drivers, 0-10v/triac/DALI

       dimmable led drivers, enclosure power suppliers, power adapters.



Q2. What's shipping mode can we choose?

A2:1.FedEx/DHL/UPS/TNT/Express for samples;

      2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;

      3. Customers specifying freight forwarders or negotiable shipping methods!



Q3. What's the MOQ?

A3: Our MOQ is 500pcs, but we accept your trail order/small order, no problem.



Q4. What can you do if the product is broken?

A4: We promise to replace new ones to you if there is any defective happen during

      the warranty period, but we need pictures or video to prove the defective comes

      from our quality problem.



Q5. How about the protection of product?

A5: Most of our products have protection of short-circuit, overload, over voltage,

       over current and reserve polarity. About the specific product, please consult

       our sales stuff.



Q6. How about the transportation?

A6: For small order,express will be best.And for bulk order,sea ship way is best but

       take much time. For urgent orders,we suggest via air to airport plus our ship partner

       send to your door. We will cooperate with your choice.



Q7. What's the Payment do you have?

A7: To assure you the maximum comfort and satisfaction, Currently, you can pay via

        T/T, L/C, WESTERN UNION, PAYPAL. More payment options will be added in the

        near future.
