The universal plug for the DMX512 signal of the Constant voltage DMX512 led driver is XLR XLR, most of which are 3PIN, and the definitions of the 3 pins are PIN1: GND; PIN2: DATA-(B); PIN3: DATA+(A).
The signal transmission mode output by DMX512 dimmable led driver is: RS485 differential signal transmission, which effectively guarantees the reliability of its signal and long-distance transmission, generally within 200 meters Normal communication.
RS485 transmission mostly only supports up to 32 unit loads (and DMX lamps) per segment. As the project uses more than 32 lamps, a signal amplifier needs to be connected in series to drive the remaining 32 Lamps within one.
The DMX lamp controlled by DMX512 led dimmable power supply has its own independent ID and address code, and its settings usually have two modes. 1: The lamp itself has an address coding function, which can be realized by pressing buttons or dialing switchesWrite the address code of the lamp; 2: The lamp relies on an external code writer to write the address code of the lamp.
