Model

SMT-012-045VM

SMT-024-045VM

SMT-036-045VM

SMT-048-045VM

output

DC Voltage

12V

24V

36V

48V

Voltage Tolerance

±0.5V

Rated current

0~3.75A

0~1.87A

0~1.25A

0~0.93A

Rated power

45W

input

Voltage Range

100-130VAC / 170-265VAC

Frequency Range

47~63HZ

Power Factor (Typ.)

PF>0.90/110V  / PF>0.90/220V

Efficiency(Typ.)

>88%

>88%

>88%

>88%

AC Current(Typ.)

          0.52A@110VAC

         0.26A@220VAC

0.25A

Leakage current

<0.60mA/110VAC / <0.70mA/220VAC

Protection

Short Circuit

Hiccup mode, recovers automatically after fault condition is removed

Over Loading

<120%

Environment

Working TEMP.

-40~+60℃

Working Humidity

20~90%RH, non-condensing

Storage TEM.,Humidity

-40~+80℃,10~95%RH

TEMP.coefficient

±0.03%/℃(0~50℃)

Vibration

10~500Hz,2G 10min./1 cycle,period for 60min. each along X,Y,Z axes

Safety&EMC

Safety standards

EN61347-1 EN61347-2-13

Withstand voltage

I/P-O/P:3.75KVAC

Isolation resistance

I/P-O/P:100MΩ/500VDC/25℃/70%RH

EMC EMISSION

EN55015,EN61000-3-2,3 (>50%loading)

EMC IMMUNITY

EN61000-4-2,3,4,5,6,11(Surge 4KV)

Others

Net.Weight

0.55Kg

Size

180*60*34mm(L*W*H)

packing

355*215*215mm/20pcs/CTN

Notes

1. All parameters NOT specially mentioned are measured at 110V / 220VAC input , rated load

and  25℃of ambient temperature.

2. Tolerance: includes set us tolerance, line regulation and load regulation .

3. The power supply is considered as a component that will be operated in combination with final Equipment. Since EMC performance will be affected by the complete installation, the final  equipment manufactures must be-qualify EMC Directive on the complete installation again
