constant voltage led driver 12v 18w
|
|
constant voltage led driver 12v 18w is IP20 design for indoor installations, 100% full load burn-in test, Suitable for LED lighting, Products through CE, ETL,RoHS Certification, 2 years warranty |
Features of led driver 12v
IP20 design for indoor installations
Protections:Short circuit/Overload/Over temperature
Cooling by free air convection
100% full load burn-in test
Suitable for LED lighting
Products through CE, ETL,RoHS Certification
2 years warranty
| SPECIFICAION | |||||
| MODEL | SMT-012-018VW | SMT-024-018VW | |||
| OUTPUT | DC VOLTAGE | 12V | 24V | ||
| RATED CURRENT | 1.5Amp | 0.75Amp | |||
| VOLTAGE RANGE | |||||
| RATED POWER | 18Watt | 18Watt | |||
| RIPPLE&NOISE(max) | 300mV | 300mV | |||
| VOLTAGE TOLERANCE | ±5% | ±5% | |||
| LINE REGULATION | ±1% | ±1% | |||
| LOAD REGULATION | ±2% | ±2% | |||
| INPUT | VOLTAGE RANGE | 100-265VAC | 100-265VAC | ||
| FREQUENCY RANGE | 47-63Hz | 47-63Hz | |||
| POWER FACTOR(Typ.) | |||||
| EFFICIENCY(Typ.) | >83% | >84% | |||
| AC CURRENT(Typ.) | 0.13A/110,220VAC | 0.23A/110,220VAC | |||
| PROTECTION | SHORT CIRCUIT |
Protection type:recovers automatically after condition is removed |
|||
| OVER CURRENT | overload protected@145-160% above peak rating | ||||
| OVER VOLTAGE | Protection type:Shut down o/p voltage,re-power on to removed | ||||
| ENVIRONMENT | WORKING TEMP. | ‘-10C+40℃ (Refer to output load derating curve) | |||
| WORKING HUMIDITY | 20~99% RH non-condensing | ||||
| STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH | ||||
| SAFETY&EMC | SAFETY STANDARDS | EN61347-1;EN61347-2-13; UL /CE /ROHS approval | |||
| WITHSTAND VOLTAGE | I/P-O/P:2KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||||
| EMC Test Standards | EN55015;EN61000-3-2;EN61000-3-3; | ||||
| EN61547;EN61000-4-2,3,4,5,6,8,11; | |||||
| NOTE |
1.All parameters NOT specially mentoned are measured at 110V,220VAC input, rated load and 25℃ of ambient temperature. 2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor. 3.Tolerance:includes set up tolerance,line regulation and load regulation. |
||||
| Label |
 |
||||
 |
 |
 |
 |
