Model |
SMT-012-060VT |
SMT-024-060VT |
|
|
Certificates |
ETL、CE、FCC |
ETL、CE、FCC |
|
|
output |
DC Voltage |
12V |
24V |
|
Voltage Tolerance |
±0.5V |
||
|
Rated current |
5A |
2.5A |
|
|
Rated power |
60W |
||
|
input |
Voltage Range |
100～130VAC / 170-265VAC |
|
|
Frequency Range |
47～63HZ |
||
|
Power Factor （Typ.） |
PF≥0.68 |
||
|
Efficiency（Typ.） |
>84% 84% |
>84% |
|
|
AC Current（Typ.） |
0.95A@110VAC |
0.48A@220VAC |
|
|
Leakage current |
﹤0.50mA @120VAC / ﹤0.65mA @220VAC |
||
|
Protection |
Short Circuit |
Hiccup mode, recovers automatically after fault condition is removed |
|
|
Over Current |
≤1.2*I out |
||
|
Over Loading |
≤120% |
||
|
Over temperature |
100℃±10℃ (The output voltage will turn off when the temperature is higher then100℃±10℃, after the temperature drop off ,it will recovery automatic
|
||
|
Environment |
Working TEMP. |
-40～+60℃ |
|
|
Working Humidity |
20～90%RH, non-condensing |
||
|
Storage TEMP. Humidity |
-40～+80℃，10～95%RH |
||
|
TEMP .coefficient |
±0.03%/℃（0～50℃） |
||
|
Vibration |
10～500Hz，2G 10min./1 cycle,period for 60min. each along X,Y,Z axes
|
||
|
Safety& EMC |
Safety standards |
UL1310 & UL8750 |
|
|
Withstand voltage |
I/P-O/P:1500VAC |
||
|
Isolation resistance |
I/P-O/P：100MΩ/500VDC/25℃/70%RH |
||
|
EMC EMISSION |
FCC Part 15 B |
||
|
others |
Net. Weight |
0.45Kg (only the dimmable Driver) |
1.0Kg (Dimmable driver + junction box) |
|
Carton Size |
180*60*35mm（L*W*H） |
350*77*37mm（L*W*H） |
|
|
packing |
350*195*180mm 20PCS/CTN |
385*335*200mm 20PCS/CTN |
|
|
Notes |
1. All parameters if NOT specially mentioned are measured at 110VAC input , rated load and 25℃of ambient temperature. 2. To extend the driver's using life ,please reduce the loading at lower input voltage. 3.Loading should be 5-100%. |
||
| Label |
  |
||
 |
 |
 |
 |
Features
- Built-in PFC function
- Efficiency > 85%
- Protections:Short circuit/over Voltage
- Fully isolated aluminum housing
- Easy installation
- Cooling by free air convection
- Work with leading edge and trailing edge TRIAC dimmers
- Strong compatibility, flicker-free dimming
- Suitable for LED lighting and moving sign applications
- Compliance to worldwide safety regulations for lighting
- 3 years warranty (We promise to replace new ones to you if there is any defective happen during the warranty period)
Specifications
- AC-DC Triac Dimmable LED Driver
- I/P:90-135vAC , 170-265VAC,47-63Hz
- Ambient temp.:-20 degree~40 degree full load
- Efficiency> 85%
- PFC > 0.95
- overload,over heat, over voltage, short circuit protection
Environment
- Working Temperature : -25 ~ +50°C
- Working Humidity : 20 ~ 90% RH non-condensing
- Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
- TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
- Vibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety
- Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529 , IP67 approved
- Withstand Voltage : I/P-O/P: 3000KVAC
- Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Applications
- indoor LED illuminating lights, LED Neon
- LED urban Decoration,LED Lighting Advertising
- LED Display, Safety Protection Apparatus
- Telecommunications, Networks
- Vehicle Lights, Controller Panels
